Capitol Water Tanks is proud to be an authorized dealer of Pioneer Water Tanks, the leading manufacturer of corrugated water storage tanks in the industry.  Each tank is built on site eliminating the need for heavy machinery on your property.  Ranging in size from 5,000 to 100,000 or more, these tanks are built to last.  With a 20-year manufacturer warranty, you are assured your water source is fresh for years to come.

Pioneer Water Tanks has supplied water tank solutions for all types of farming, domestic and agricultural applications since 1988. Designed for harsh and demanding conditions, Pioneer Water Tanks are manufactured using strong and durable, fully recyclable 100% Zincalume® or Colorbond® steel.  The range of tanks, supplied by Capitol Water Tanks, are available from 5,000 to 100,0000-Gallons in our standard range or can be custom built up to one million gallons.  We offer a full range of accessories and fittings so that your tank meets your needs and performs to the highest standards.

The AQUALINER® Fresh tank liner used in Pioneer Water Tanks is NSF/ANSI 61 certified for drinking water storage. The National Safety Foundation standards for drinking water are developed by a team of scientists and industry experts to guarantee products worldwide.

NSF/ANSI 61 certified materials are safe for drinking water storage and are not made with the chemical BPA. The quality of materials ensures that the liner never imparts a taste to keep your water as fresh as the day it first entered the tank.

Pioneer Water Tanks are engineered to NFPA standards for water storage for fire protection. The tank body and roof are made of Zincalume® Steel, which is proven to withstand fire immersion. The tank’s firefighting adapters and nozzles are compatible with fire hoses across North America.

Standard XLR Series tank kit includes:

• Galvalume tank body, trusses and roof sheets, top hoop
• AQUALINER Fresh®
• Geotextile underlay and condensation barrier
• Lockable roof access hatch and ladder
• 2” outlet with ball valve
• 6” overflow
• Inlet basket strainer (for rainwater catchment – a 2″ threaded, top sidewall fitting may be used in lieu of the basket strainer in water well applications)
• Sacrificial anodes for rust prevention

ONLY PIONEER HAS OVER 30-YEARS OF PROVIDING…

1. The AQUALINER® Fresh, the only antimicrobial tank liner in the world.

2. The PIONEER V-LOCK® tank wall profile provides the strength of corrugated steel and maintains support for the liner while minimizing stress.

3. The industry-leading 20–year conditional warranty on the tank and liner.

4. The heavy-duty roof truss system, manufactured for extreme conditions.

5. Our standard accessories and commercial upgrades expand the functionality of your tank.

FEATURES & BENEFITS

• Readily available water storage tanks range from 5,000 gallons up to 65,000 gallons.
• Tank capacities of more than 100K Gallons are also available with 90-120 day lead times.
• AQUALINER® water storage liners provides a flexible, long lasting and high quality tank system.
• Innovative, fully enclosed bolt cap hides bolts on outside of tank for a more aesthetically pleasing look.
• Standard 20 year warranty (Conditions apply)
• Equipped with roof to reduce evaporation & provide a barrier against foreign matter.
• Residential tanks are designed to be constructed on a 6″ deep sand pad with a rock border around the perimeter to prevent erosion.
  (In some cases, concrete ring beam foundations are recommended.)
• In many cases, the Pioneer tank may be used with fire suppression projects.
